MDF-1156-PE - Compact Ultra-Low Temperature Freezer
The cryogenic ultra-low temperature freezer type MDF-1156-PE is a mechanically cooled cryogenic freezer without harmful CFCs. This ultra-low temperature freezer enables stable long-term preservation of cells and tissues. The PHCbi ultra-low temperature preservation system type MDF-1156-PE uses modern technology to ensure highly accurate temperatures.
A specially designed compressor and a cascade cooling system for ultra-low temperatures down to -152°C.
The highly efficient compressors are specifically developed for ultra-low temperature equipment. A cooling circuit with a cascade cooling system increases the reliability of long-term storage. Thanks to its powerful low-noise design based on traditional ultra-low temperature technology, this freezer ensures sustainable and stable cooling.
Features
- The ultra-low temperature freezer down to -150°C with the world’s largest capacity
- Rechargeable battery
- Application of a special ultra-low temperature compressor
- PHCbi’s patented V.I.P. Plus vacuum insulation panel for high density.
- Three cabinet security levels
- PHCbi-designed quiet high-performance cooling
- PHCbi’s mixed refrigerant contains no CFCs
- Enhanced reliability for long-term preservation
- Modern control functions
- LED digital display and membrane keyboard for accurate temperature setting, confirmation, and operation
- The inner chamber safely maintains a temperature below -130°C
- Ultra-low temperature is generated by a highly efficient oil separator
- Specially foamed polyurethane insulation for maximum cabinet protection
- Microprocessor-controlled check function for clogged filters
- High temperature warning device
- Power failure alarm light and buzzer
- Remote alarm contact
![](https://a8b746f2.rocketcdn.me/wp-content/uploads/2023/11/MDF-1156-PE-perfm-1024x994.jpg)
![Dimensions_MDF_1156ANT_PE](https://a8b746f2.rocketcdn.me/wp-content/uploads/2023/11/Dimensions_MDF_1156ANT_PE-e1710682699852.png)
External dimensions (W x D x H) | 1400 x 800 x 945 mm |
---|---|
Internal dimensions (W x D x H) | 500 x 450 x 572 mm |
Volume | 128 Liter |
Net weight (approx.) | 265 kg |
Capacity (aluminum racks 2” boxes) | 81 |
Capacity (stainless steel racks 2” boxes) | 81 |
Cooling performance | -152 °C |
Temperature setting range | -125 to -155 °C |
Temperature control range | -130 to -152 °C |
Controller | Microprocessor, non-volatile memory |
Display | LED |
Temperature sensor | Pt-100 |
Cooling system | Cascade |
High pressure compressor | 1100 W |
Refrigerant | R-407D / MU-N711A |
Insulation material | PUF |
Insulation thickness | 175 mm |
Exterior | Painted steel |
Interior | Aluminum |
Exterior door | – |
Exterior door lock | J |
Interior door | J |
Shelves | |
Max. Load per shelf | – |
Max. Total load | 300 kg |
Vacuum release port | – |
Access port | 1 |
Access port position | Left |
Access port diameter | 40 |
Casters | 6 (2 adjustable feet) |
Power failure | O-A-F |
Temperature too high | O-A-F |
Temperature too low | – |
Filter | O-A |
Door open | – |
Power supply | 230 V |
Frequency | 50 Hz |
Volume | 52 dB [A] |
Number of LVL SBS racks per freezer | ||||||||||||
PHCBi Model | SX300 | MX500 | LX1000 | MI500 | LI1000 | XLX500 | XLX2000 | XLX4000 | XXLX2000 | XXLX4000 | XXLX6000 | XXLX8000 |
MDF-1156-PE | 330 | 240 | 150 | 210 | 150 | 345 | 150 | 90 | 255 | 180 | 135 | 105 |
